FDA/ICH Stability Test Chamber Specs



Chamber Specifications

Chamber
Model
Capacity
(Approx.)
Doors Shelving
Area
Ext. Dimensions
WxDxH
Int. Dimensions
WxDxH
Electrical
Volts/Ø/Amps
Shipping
Weight
BC3100-ICH 21 ft3 1 12 ft2 27½” x 33¾” x 77¾” 22½” x 27” x 59¾” 115/1/20 475 lbs.
BC5600-ICH 44 ft3 2 24 ft2 52¾” x 33¾” x 77¾” 47½” x 27” x 59¾” 115/1/20 850 lbs.
BC8500-ICH 68 ft3 3 36 ft2 77¾” x 33¾” x 77¾” 72¾” x 27” x 59¾” 115/1/20 1,050 lbs.

Chamber Dimensions

stability chamber dimensions

Sensors

  • Band 5, 100-ohm Platinum RTD
  • Thin-film polymer capacitive humidity sensor with hermetically sealed electronics

Controls

  • Integrated multi-loop PID control with logic functionality
  • High-frequency ultrasonic humidification with independent blower
  • Precision control of heater output balanced with constant cooling capacity
  • Rear wall plenum for optimal circulation and uniformity
  • Oversized, custom fan motor for maximum airflow
Stability Chamber Features

Temperature

Temperature Range: 25°C to 40°
Temperature Control: ±0.2°C

Humidity:

Humidity Range: 60% to 90% RH
Humidity Control: ±0.7% RH

Operation

  • User-friendly BioLogic™ color touchscreen interface
  • Windows CE operating system
  • 8-inch, 640 x 480 full-color display with high-precision touch accuracy
  • Programmable ramp/soak control profiles
  • PC-based system for alarms, data-logging, chart recording, etc.
  • Web-thin client for remote internet monitoring -- dynamic, real-time viewing
    • Automatic e-mail alarm support
  • State-of-the-art data recording & trending functionality
  • Full-featured communications (2 USB, Ethernet, COM ports, compact flash)

Validation

  • IQ/OQ protocol
  • Sensor verification certificate
  • Preliminary chamber mapping report
  • Supports data encryption, standard firewall configuration, HTTPS (SSL)
  • Multi-level password protected access
  • 21 CFR Part 11 compliant

Efficiency

  • High-efficiency 1.75-inch urethane insulation
  • Magnetic gasket with heated door frame
  • High efficiency (80%) commutated fan motors
  • Adjustable refrigeration shut-off for high-temperature operation
